QSFP28/56 (zQSFP+), SFP28/56 (SFP+), OSFP, QSFP-DD, OSFP-800G, QSFP-DD-800G COMPLIANCE BOARDS

QSFP-DD-800G and OSFP-800G HCB 32 Port

$14,932.00

QSFP-DD- 800G and OSFP-800G HOST COMPLIANCE BOARD - 16 Differential Lanes

[TX1,TX2,TX3,TX4] [RX1,RX2,RX3,RX4]
[TX5,TX6,TX7,TX8] [RX5,RX6,RX7,RX8]



QSFP-DD and OSFP MSA Hardware Specification

STANDARDS: IEEE802.3ck Mated Test Fixture Specifications


IEEE802.3ck, IEEE802.3cd, IEEE802.3by, IEEE802.3bj, IEEE802.3bm, and IEEE802.3bs.

·       Connectors: 2.92 mm (SMA compatible), 2.44 mm and 1.85 mm - with Ardent TR 32 channel multicoax RF cable

·       Pricing listed for 2.92 mm and 2.44 mm; 1.85 mm $15, 989.00

·       Calibration traces

·       Allow accurate deembedding of test fixture




Developed and manufactured in the USA



ATTENTION !!! ON LINE PAYMENTS NOT ACTIVE YET. PLEASE CALL/EMAIL DIRECT.
CALL FOR DISCOUNT PROGRAM !!!

Sales and technical information
PHY-SI LLC
President/CTO
Christopher DiMinico
